Direct Drive Series
Oil injected air screw compressors are equipt with airend instead of pistons. Air is compressed by two rotating rotors between two lobs towards outlet. Oil injected airend which consists of torot with asimetric helical profile, bearings and housing are manufactured by state of art technology to provide maximum performance. It is called as “screw” because of the appereance of the rotors and it is the heart of the compressor.
Technicial Specifications
| Model | Flow Rate (m3/min) | Motor Power | Voltage Phase | Air Output | Dimensions (W x L x H) | ||
| 7 | 10 | 13 | kW/hp | volt | inch | mm | |
| ALK-22 D | 4,08 | 3,4 | 2,55 | 22/30 | 400/3 | 11/4" | 850X1390X1560 |
| ALK-30 D | 5,5 | 4,93 | 3,68 | 30/40 | 400/3 | 11/2" | 1150X1900X1500 |
| ALK-37 D | 6,38 | 5,55 | 5,02 | 37/50 | 400/3 | 11/2" | 1150X1900X1500 |
| ALK-45 D | 7,6 | 7,28 | 6,26 | 45/60 | 400/3 | 11/2" | 1150X1900X1500 |
| ALK-55 D | 9,47 | 9,28 | 7,27 | 55/75 | 400/3 | 2" | 1300X2200X1800 |
| ALK-75 D | 12,06 | 11,98 | 8,96 | 75/100 | 400/3 | 2" | 1300X2200X1800 |
| ALK-90 D | 16,24 | 13,2 | 11,86 | 90/125 | 400/3 | 2" | 1500X2650X2235 |
| ALK-110 D | 19,46 | 16,14 | 13,08 | 110/150 | 400/3 | 2" | 1500X2650X2235 |
| ALK-132 D | 22,06 | 19,31 | 15,98 | 132/180 | 400/3 | 2" | 1500X2650X2235 |
| ALK-160 D | 26,38 | 24,38 | 20,75 | 160/220 | 400/3 | 21/2" | 1740X3000X2555 |
| ALK-200 D | 34,5 | 30,76 | 24 | 200/270 | 400/3 | 21/2" | 1740X3000X2555 |
| ALK-250 D | 44,2 | 37,6 | 30,58 | 250/340 | 400/3 | 3" | 1920X3400X2636 |
| ALK-315 D | 55 | 43,76 | 41,61 | 315/420 | 400/3 | 3" | 1920X3400X2636 |
- Alkin Compressor reserves the right to change the information and pictures in its brochures without prior notice.
Standard Features
- High Performance L Profile Poly V Belt
- Safety Valve
- High Efficiency Electric Motor
- Phase and Motor Protection Relays
- Double Stage Full Oil Separation System with Immersion Type Separator
- Fire Retardant Sound Insulation
- Ergonomic Cabinet Design for Easy Access and Maintenance
- High Pressure Error Alarm/Stopper
- High Temperature Alarm/Stopper
Optional
Sectors
Frequently Asked Questions
Air compressors work by compressing atmospheric air in a smaller volume of piston-cylinder, screw, etc. and pressurize it depending on your special needs.
Piston compressors are sufficient for short-term high pressure air needs. If you need a long-life, low-pressure compressor that provides continuous airflow, the screw compressor should be your primary choice.
Alkin Compressors always endeavours to respond to customer enquiries as soon as possible. Please visit contact page our opening times for further information regarding Alkın Compressors’s office hours.
Air/gas compressors produced by Alkın Compressor come with a 2-year warranty, providing they are serviced by ourselves. However, longer warranties for compressors are available on request.
